Print head 4.0

NETTO PRICE 280 €


All-metal print head forclay, highly viscous pastes and suspensions. Powered by Nema17 stepper motor, to be used in desktop 3d printers and custom-built clay printers. Combines durability and precision of CNC-milled construction with simple-to-use and attractive design. The stator and screw can be easily dismounted/installed in less than a minute. Inlet can be oriented in four different ways to fit your equipment.

333,20 €

  • 0,7 kg
  • Available
  • Ships within 1 week1

Features:

  • perfect flow control (start/stop without delays), thanks to specially designed two-flute auger screw
  • sealed leak-free construction
  • durable auger screw from polished stainless steel, stator from AL6061-T6 alloy
  • Durable and strong 4mm thick metallic mount. Stator with seven threaded M5 channels, and standard 1/2 and 1/4 inch holes with NPT thread for inlet and outlet respecively.



Specifications:

  • Dimensions WxDxH = 42x72x124mm (without nozzle)
  • Screw length 62mm, diameter 8mm
  • Inlet: push-in connector for 16mm pipe (external diameter)
  • Outlet: 1/4 NPT threaded hole for up to D=8mm ouput flow
  • Comes with metallic nozzles: 2.5mm, 4mm, 7mm, nozzle adapter for standard luer tips, 6 different PE luer tips (0.2mm ... 1.55mm)
  • Stepper motor Nema17, 2.5A/phase, 40Ncm, 2-phase, 1.8deg.



This is a spare part! While the print head can be directly connected to the motherboard of a 3D printer, we recommend to use this as a part of 3D Printing KIT and connect to the printer via Control Unit. When used without control unit, this may need to change settings of your stepper motor driver. In case of questions please contact us.

Download
Dimensions of the print head
SF-Print_head_4_dimensions.PDF
Adobe Acrobat Document 37.4 KB

Print head 4R

NETTO PRICE 330 €



Reinforced print head for clay, highly viscous pastes and suspensions. Powered by geared stepper motor (gear ratio on your choice), to be used in desktop 3d printers and custom-built clay printers. Combines durability and precision of CNC-milled construction with simple-to-use and attractive design. The stator and screw can be easily dismounted/installed in less than a minute. Inlet can be oriented in four different ways to fit your equipment.

392,70 €

  • 0,8 kg
  • Available
  • Ships within 1 week1

Features:

  • perfect flow control (start/stop without delays), thanks to specially designed two-flute auger screw
  • sealed leak-free construction
  • durable auger screw from polished stainless steel, stator from AL6061-T6 alloy
  • Durable and strong 4mm thick metallic mount. Stator with seven threaded M5 channels, and standard 1/2 and 1/4 inch holes with NPT thread for inlet and outlet respecively.



Specifications:

  • Dimensions WxDxH = 42x72x124mm (without nozzle)
  • Screw length 62mm, diameter 8mm
  • Inlet: push-in connector for 16mm pipe (external diameter)
  • Outlet: 1/4 NPT threaded hole for up to D=8mm ouput flow
  • Comes with metallic nozzles: 2.5mm, 4mm, 7mm, nozzle adapter for standard luer tips, 6 different PE luer tips (0.2mm ... 1.55mm)
  • Stepper motor Nema17, 2.5A/phase, 40Ncm, 2-phase, 1.8deg.



This is a spare part! While the print head can be directly connected to the motherboard of a 3D printer, we recommend to use this as a part of 3D Printing KIT and connect to the printer via Control Unit. When used without control unit, this may need to change settings of your stepper motor driver. In case of questions please contact us.

Print head 5S

NETTO PRICE 369 €


Print head from stainless steel 304, for more durability and corrosion-resistance. All-metal inlet adapter (nikel-plated bronze). Facilitated installation of the stator. Includes standard Nema17 stepper motor, cables, nozzle set. Perfect for mortars, clay, corrosive and abrasive pastes and suspensions. Inlet can be oriented in four different ways to fit your equipment.

439,11 €

  • Available
  • Ships within 1-3 days1

Features:

  • strenghtened two-flute auger screw (SS 304)
  • leak-free construction, easily replaceable standard seal and bearing
  • durable auger screw from polished stainless steel, stator from AL6061-T6 alloy
  • Durable and strong steel mount. Stator with seven threaded M5 channels, and standard 1/2 and 1/4 inch holes with NPT thread for inlet and outlet respecively.



Specifications:

  • Dimensions WxDxH = 42x72x124mm (without nozzle)
  • Screw length 62mm, diameter 8mm
  • Inlet: push-in connector for 16mm pipe (external diameter)
  • Outlet: 1/4 NPT threaded hole for up to D=8mm ouput flow
  • Comes with metallic nozzles: 2.5mm, 4mm, 7mm, nozzle adapter for standard luer tips, 6 different PE luer tips (0.2mm ... 1.55mm)
  • Stepper motor Nema17, 2.5A/phase, 40Ncm, 2-phase, 1.8deg.



This is a spare part! While the print head can be directly connected to the motherboard of a 3D printer, we recommend to use this as a part of 3D Printing KIT and connect to the printer via Control Unit. When used without control unit, this may need to change settings of your stepper motor driver. In case of questions please contact us.

Print head 5SR

NETTO PRICE 419 €


Reinforced print head from stainless steel 304 with geared stepper motor (5:1). Maximum durability, corrosion-resistance and torque. All-metal inlet adapter (nikel-plated bronze). Facilitated installation of the stator. Includes cable, two-flute auger screw, nozzle set. For very viscous corrosive and abrasive pastes and suspensions. Inlet can be oriented in four different ways to fit your equipment.

498,61 €

  • Available
  • Ships within 1-3 days1

Features:

  • Geared stepper motor Nema 17 (5:1 gear ratio)
  • strenghtened two-flute auger screw (SS 304)
  • leak-free construction, easily replaceable standard seal and bearing
  • durable auger screw from polished stainless steel, stator from AL6061-T6 alloy
  • Durable and strong steel mount. Stator with seven threaded M5 channels, and standard 1/2 and 1/4 inch holes with NPT thread for inlet and outlet respecively.



Specifications:

  • Dimensions WxDxH = 42x72x124mm (without nozzle)
  • Screw length 62mm, diameter 8mm
  • Inlet: push-in connector for 16mm pipe (external diameter)
  • Outlet: 1/4 NPT threaded hole for up to D=8mm ouput flow
  • Comes with metallic nozzles: 2.5mm, 4mm, 7mm, nozzle adapter for standard luer tips, 6 different PE luer tips (0.2mm ... 1.55mm)
  • Stepper motor Nema17, 2.5A/phase, 40Ncm, 2-phase, 1.8deg.



This is a spare part! While the print head can be directly connected to the motherboard of a 3D printer, we recommend to use this as a part of 3D Printing KIT and connect to the printer via Control Unit. When used without control unit, this may need to change settings of your stepper motor driver. In case of questions please contact us.

Nozzle set (print head 4.0)

NETTO PRICE 40 €



Conical Luer nozzles (PE) of 6 different diameters:

Dark Green - 14 Gauge - 1.55mm

Black - 16 Gauge - 1.19mm

Jade Green - 18 Gauge - 0.84mm

Light pink - 20 Gauge - 0.6mm

Royal blue - 22 Gauge - 0.41mm

Red - 25 Gauge - 0.26mm

- Luer adapter (D about 2mm)

- Bronze nozzles with diameters 2.5, 4 and 7mm.

47,60 €

  • 0,01 kg
  • Available
  • Ships within 1-3 days1

Spare auger screw

NETTO PRICE 60 €





Auger screw, specially designed and optimized for clay extrusion. Includes brass bearing and seal ring. Compatible with StoneFlower print head 3.0. Wear- and corrosion-resistant polished stainless steel 304.

71,40 €

  • 0,05 kg
  • Available
  • Ships within 1-3 days1
